Roofing and Walling

CORRUGATED is made from both G550 COLORBOND® steel and ZINCALUME® steel for Long run cladding and G300 COLORBOND steel and ZINCALUME steel which is suitable for curving.

ADVANTAGES:
CORRUGATED is manufactured locally by continuously roll forming pre-finished materials, giving a low cost and high quality product.

CORRUGATED, being light and strong, it is easy to handle and can fixed quickly and efficiently. Finishing is by the pierce fixing method. A minimum of fasteners are required thus keeping building costs low.

MATERIALS SPECIFICATIONS
Regular
Curving Grade
Heritage Galvanized

G550/AZ150
G300/AZ150
G300/Z600

AUSTRALIAN STANDARDS
AS1397-2001
AS1445-1986
MASS
per unit area [kg/m]
Per unit length [kg/m]
Coverage [m2/tonne]

Regular Curving
4.27 6.02
3.26 4.59
234 166
THICKNESS
BMT[mm]
TCT[mm]

Regular Curving
0.42 0.60
0.47 0.66
ROOF PITCH [min]
5°[1 in 12]
COVERAGE
762 mm ±4
LENGTHS Factory cut to length +0-15mm
FINISH ZINCALUME® steel
COLORBOND® steel

TRIMDEK
Thickness: .42BMT
Available: Zincalume or colourbond

SPANDEK
Thickness: .42BMT, .48BMT
Available: Zincalume or colourbond

KLIP-LOK 406
Thickness: .55BMT, .70BMT
Available: Zincalume or colourbond
MULTICLAD
Thickness: .42BMT
Available: Zincalume or colourbond

PANELRIB
Thickness: ..35BMT,.42BMT
Available: Zincalume or colourbond
PANELRIB
Thickness: ..35BMT,.42BMT
Available: Zincalume or colourbond

EASYCLAD
Thickness: 35BMT,
Available: Zincalume or colourbond
TRIMWALL
Thickness: 35BMT,
Available: Zincalume or colourbond
